Home > Catalogs > Cleaning tools > Beam nozzles
BN Series Heater Exchanger & Small Tube Cleaning Head
Features
BN tube cleaning head provides the highest quality jets with no replacement parts
Application
The BN Series water jet heads are mainly used for cleaning small tubes and block pipes. It has a unique effect on cleaning heater-exchanger tube, condenser tube, the chemical pipe, etc. It is usually used with a Flex-Lance or a Rigid lance.
| Model | BN150-10 | BN 150-13 | BN 150-18 | BN 150-24 | BN 150-33 | BN280-13 | BN280-18 | BN280-27 |
| For tube ID (mm) | 12.7-16 | 16-25 | 22-38 | 29-51 | 38-50 | 16-25 | 22-38 | 32-51 |
| Max pressure (Bar) | 1500 | 1500 | 1500 | 1500 | 1500 | 2800 | 2800 | 2800 |
| Body Diameter(mm) | 9.5 | 12.7 | 17.6 | 24 | 33 | 12.7 | 17.6 | 27 |
| Length (mm) | 65.27 | 73.7 | 96.5 | 130 | 175 | 73.7 | 119 | 140 |
| Input port | M7 | 3/8-24L | 9/16-18L | 9/16-18L | 1/2NPT | 3/8-24LH | 3/8-24LH | 9/16-18LH |
 |
 |
 |
| Polisher Heads Designed to remove thin hard scale. Ideal for IRIS inspections. |
Unplugger Heads This jetting option is designed to clean the toughest plugged tubes. |
Universal Heads Designed to unplug and polish at the same time. |
Selection instructions
After selecting the head type, then to choose the Head pressure and water flow, which usually match with pump's actual pressure and water flow.
HY-B Series HP Rotating cleaning head
Features:
HY-B heads is a kind of polisher head used to cleaning inner surface of small tube,It’s 45°
Back jetting power will push head go ahead.
| NO. | Model | Pressure(Bar) | Out.Dia | Length | Connection type |
| 1 | HY-B100-10 | 1000 | 10 | 50 | M7*1F |
| 2 | HY-B100-12 | 1000 | 12 | 31 | 1/8” |
| 3 | HY-B100-16 | 1000 | 16 | 41 | 1/8” |
| 4 | HY-B100-12L | 1250 | 12 | 55 | 1/8”BSPF |
| 5 | HY-B100-28L | 1000 | 28 | 115 | 1/8”BSPF |
